SKF offers a wide range of portable, lightweight and easy-to-use infrared thermometers for thermal inspections. These portable tools help you to detect temperature differences in technical and non-technical applications in order to perceive information on abnormalities in operating. For example helping to prevent high costs of losses in equipment, prevent unplanned stops and to meet food safety requirements.

SKF Infrared Thermometers are fitted with multiple lasers which helps you to easy and more accurate target the object.

Product highlights:

• LCD colour display
• 8 laser targeting
• Type-K thermocouple probe TMDT 2-30
• Adjustable emissivity
• High accuracy
• Fast response time
• DS ratio of 30:1
• Can be used with any SKF temperature probe
• User selectable, multiple temperature measurement modes including: maximum, minimum, average, differential and probe/infrared dual display, scan function
• User selectable high and low alarm levels with audible warning signal
• Mode dependant auto shut off feature optimises battery life
• Temperature range using infrared: -60 to +760 ºC (-76 to +1 400 ºF)
• Temperature range using probe: –64 to +1 400 °C (–83 to +1 999 °F)
• Emissivity pre-set: 0,1–1,0
• Supplied in a sturdy carrying case

Technical data:

• Temperature range using infrared: -60 to +760 ºC (-76 to +1 400 ºF)
• Temperature range using probe: -64 to +1 400 ºC (-83 to +2 552 ºF)
• Probe supplied: TMDT 2-30 included max. 900 °C (1650 °F)
• Distance-to-spot ratio: 30:1
• Emissivity: 0,1-1,0
• Measurement accuracy: +/-2% of reading or 2°C (4°F) whichever is greater
• Operating temperature: 0 to +50 ° C 10 to 95% R.H.
• Storage  -10 to +60° C: (14 to +140 °C)  10 to 95% R.H.
• Respons time msec: 1000
• Displayed resolution: 0.1 °C/F (below 999.9); 1 °C/F (above 1000)
• Display Colour: backlit LCD
• Spectral response: 8-14 µm
• Measurement modes: Maximum; Minimum; Average; Difference (between min and max); Probe/IR dual temperature
• Alarm modes: High and low level alarm with warning sound
• Laser: 8x red targeting laser dots, Class 2
• Operating time: Min. 30 hours continuous use without laser
• Auto switch off: Automatic, 60 seconds after trigger release in IR mode and 12 minutes after trigger release in probe mode

Contents:

• 1x IR thermometer (TKTL 21);
• 1x Temperature probe (TMDT 2-30);
• 2x AAA Alkaline batteries;
• 1x Instructions for use;
• 1x Carrying case
